Introduction

This module contains an implementation of ERC-6224: Contracts Dependencies Registry.

We highly recommend reading the EIP before proceeding. This documentation provides a genuine follow up guide for the technical EIP description.

The Contracts Registry module streamlines the maintenance of large projects by offering a comprehensive solution for organizing contracts, handling their interdependencies, and enabling seamless system upgrades. Its main features include:

• A unified repository for all system contract addresses, ensuring easy access.
• Dynamic contract addition, removal, and replacement.
• A dependency injection mechanism to effectively manage smart contract dependencies.
• Automated management of proxy contracts.
• Compatibility with both standalone and pool contracts.

Implementation

Contracts Registry architecture

1 ContractsRegistry contract

The AContractsRegistry is a contract that should be used as the highest level repository that is aware of all other contracts present in the system.

Behind the scenes, the AContractRegistry maintains a mapping of string contract names to their corresponding addresses. The use of string keys, selected by ERC-6224 for their high readability, is favored even though it might not be the most gas-efficient option. Generally, the AContractRegistry adds system contracts under the self-deployed transparent proxies, gaining the rights to use administrative methods on these proxies, such as upgradeTo. It also permits adding pre-deployed contracts, regardless of their proxy status. However, users should set up permissions for these contracts themselves.

Functions featured by the AContractsRegistry:

Function	Description
injectDependencies, injectDependenciesWithData	Injects the dependencies into the given contract
upgradeContract, upgradeContractAndCall	Upgrades added proxy contract with a new implementation
addContract	Adds contracts that the system does not have direct upgradeability control over, or the contracts that are not upgradeable
addProxyContract, addProxyContractAndCall	Adds the contracts and deploys the proxy above them
justAddProxyContract	Adds the already deployed proxy
removeContact	Removes the contract

2 Dependency Injection

The AContractsRegistry works together with ADependant contracts. Every standalone contract of a protocol must be ADependant in order to support the dependency injection mechanism. The required dependencies must be set in the overridden setDependencies method, not in the constructor or initializer methods. The setDependencies function has the ContractsRegistry as a parameter, so the required dependencies can be retrieved from it. Unlike initializer methods, the setDependencies might be called as much as needs.

3 PoolRegistry and PoolFactory contracts

To facilitate the deployment and management of pool contracts, the APoolRegistry and APoolFactory contracts are essential. Both of them are ADependant and typically included into the AContractsRegistry. These contracts utilize the Beacon Proxy to enable simultaneous upgrades of pools. Dependency injection for ADependant pool contracts is performed by the APoolFactory upon initial deployment and by the APoolRegistry for existing pools.

Functions featured by the APoolRegistry:

Function	Description
setNewImplementations	Sets pools' implementations
injectDependenciesToExistingPools, injectDependenciesToExistingPoolsWithData	Injects dependencies to the pools
addProxyPool	Adds new pools

Functions featured by the APoolFactory:

Function	Description
deploy	Deploys Beacon Proxy pointing to the pool implementation taken from the PoolRegistry
deploy2	Deploys Beacon Proxy pointing to the pool implementation taken from the PoolRegistry using the create2 mechanism
register	Registers the newly deployed pool in the PoolRegistry
injectDependencies	Injects dependencies into the newly deployed pool and sets PoolRegistry as an injector

4 Presets

The Contracts Registry module includes several preset contracts to help you establish permissions.

Function	Description
OwnableContractsRegistry	Only the owner can inject dependencies into, add, remove, and upgrade contracts
MultiOwnableContractsRegistry	Only multiple owners can inject dependencies into, add, remove, and upgrade contracts
OwnablePoolContractsRegistry	Only the owner can call set pools' implementations and inject dependencies into existing pools
MultiOwnablePoolContractsRegistry	Only multiple owners can call set pools' implementations and inject dependencies into existing pools

Example

To set up a system, start by creating the ContractsRegistry contract, which inherits from the OwnableContractsRegistry. This preset ensures that only the owner can use methods for managing contract addresses and performing dependency injections.

Assume the system has two standalone contracts, named SystemContract1 and SystemContract2, each associated with a unique string identifier. It is recommended to establish constants within the ContractsRegistry to signify the contracts it includes, such as SYSTEM_CONTRACT_1 and SYSTEM_CONTRACT_2. Furthermore, it is beneficial to introduce functions that enable the retrieval of contract addresses using these constants. The ContractsRegistry is intended to be an upgradeable contract, e.g. UUPSUpgradeable, but for the sake of simplicity we leave it as it is.

import "@solarity/solidity-lib/presets/contracts-registry/OwnableContractsRegistry.sol";

contract ContractsRegistry is OwnableContractsRegistry {
    string public constant SYSTEM_CONTRACT_1 = "SYSTEM_CONTRACT_1";
    string public constant SYSTEM_CONTRACT_2 = "SYSTEM_CONTRACT_2";

    function getSystemContract1() external view returns (address) {
        return getContract(SYSTEM_CONTRACT_1);
    }

    function getSystemContract2() external view returns (address) {
        return getContract(SYSTEM_CONTRACT_2);
    }
}

Now, let's create system contracts. In this example, SystemContract1 is designed to work with SystemContract2 as a dependency. It inherits from ADependant to implement the necessary dependency handling. The setDependencies function allows SystemContract1 to retrieve the address of SystemContract2 from the ContractsRegistry. Note that the dependant modifier is applied to the setDependencies method, ensuring that only the injector, typically the ContractsRegistry, can call it.

contract SystemContract1 is ADependant {
    address public systemContract2;

    function setDependencies(
        address contractsRegistry_,
        bytes memory
    ) public override dependant {
        systemContract2 = ContractsRegistry(contractsRegistry_).getSystemContract2();
    }

    function systemContract1Method() external { /* ... */ }
}

contract SystemContract2 {
    /// ...
}

To initiate the migration process, begin by deploying and initializing the ContractsRegistry contract. Following this, deploy all system contracts and register them. In this example, SystemContract1 is deployed under the transparent proxy managed by ContractsRegistry, while SystemContract2 is added as is. Conclude by injecting dependencies into the SystemContract1.

function migration() external {
    ContractsRegistry contractsRegistry_ = new ContractsRegistry();

    contractsRegistry_.__OwnableContractsRegistry_init();

    SystemContract1 systemContract1_ = new SystemContract1();
    SystemContract2 systemContract2_ = new SystemContract2();

    contractsRegistry_.addProxyContract(
        contractsRegistry_.SYSTEM_CONTRACT_1(),
        address(systemContract1_)
    );
    contractsRegistry_.addContract(
        contractsRegistry_.SYSTEM_CONTRACT_2(),
        address(systemContract2_)
    );

    contractsRegistry_.injectDependencies(contractsRegistry_.SYSTEM_CONTRACT_1());

    contractsRegistry_.transferOwnership(msg.sender);
}

Now we may want our system to support pool contracts. Pool contracts are designed to be deployed multiple times within the same system, each instance operating with the same underlying implementation. PoolA, in particular, inherits from both ADependant and Initializable, illustrating its capabilities for dependency management and one-time initialization. These features ensure that each instance of PoolA seamlessly integrates into the system, interacting appropriately with other system components.

import "@openzeppelin/contracts-upgradeable/proxy/utils/Initializable.sol";

contract PoolA is ADependant, Initializable {
    struct Parameters {
        address token1;
        address token2;
    }

    struct Dependencies {
        address systemContract1;
    }

    Parameters public parameters;
    Dependencies public dependencies;

    function __PoolA_init(Parameters calldata parameters_) external initializer {
        parameters = parameters_;
    }

    function setDependencies(
        address contractsRegistry_,
        bytes memory data_
    ) public override dependant {
        dependencies.systemContract1 = ContractsRegistry(contractsRegistry_)
            .getSystemContract1();
    }

    function poolAMethod() external { /* ... */ }

    /// ...
}

There is no need to alter the ContractsRegistry for each pool addition. Instead, we propose utilizing the specialized PoolRegistry contract. Mirroring the approach of ContractsRegistry, PoolRegistry utilizes string keys, such as POOL_A, for pools identification. In order to facilitate the process of registering new pools, the addProxyPool function has been overridden. This modification restricts the registration of new pools exclusively to the designated factory.

import "@solarity/solidity-lib/presets/contracts-registry/pools/AOwnablePoolContractsRegistry.sol";

contract PoolRegistry is AOwnablePoolContractsRegistry {
    string public constant POOL_A = "POOL_A";

    address public poolFactory;

    modifier onlyPoolFactory() {
        require(poolFactory == msg.sender, "PoolRegistry: caller is not a factory");
        _;
    }

    function __PoolRegistry_init() external {
        __AOwnablePoolContractsRegistry_init();
    }

    function setDependencies(
        address contractsRegistry_,
        bytes memory data_
    ) public override {
        super.setDependencies(contractsRegistry_, data_);

        poolFactory = ContractsRegistry(contractsRegistry_).getPoolFactory();
    }

    function addProxyPool(
        string memory name_,
        address poolAddress_
    ) public override onlyPoolFactory {
        _addProxyPool(name_, poolAddress_);
    }
}

The PoolRegistry contract typically works in tandem with the PoolFactory contract. Note that both of them require each other as dependencies in their respective setDependencies methods. This scenario is referred to as recursive dependencies, which is also applicable within Dependant contracts.

The PoolFactory itself contains deployment methods, like deployPoolA, each tailored to a specific pool type. The process of setting up a new pool encompasses several steps:

1. Deployment: The initial task of the deployment method is to deploy a new pool. This is accomplished using either the _deploy function (for standard CREATE deployments) or the _deploy2 function (for CREATE2 deployments) from the APoolFactory. By default, these methods deploy beacon proxies, utilizing wrapped pool implementations provided by the PoolRegistry.
2. Initialization: Following deployment, much like typical upgradeable contracts, the new pool contract undergoes an initialization process.
3. Dependency Injection: After the pool is initialized, it may need specific dependencies to be fully operational. The _injectDependencies method injects dependencies to the pool and transfers injector permissions to the PoolRegistry.
4. Registration: The final phase in the setup process is the registration of the new pool contract in the registry. The _register method adds the pool to the PoolRegistry using its addProxyPool method.

import "@solarity/solidity-lib/contracts-registry/pools/APoolFactory.sol";

contract PoolFactory is APoolFactory {
    address public poolRegistry;

    function setDependencies(
        address contractsRegistry_,
        bytes memory data_
    ) public override {
        super.setDependencies(contractsRegistry_, data_);

        poolRegistry = ContractsRegistry(contractsRegistry_).getPoolRegistry();
    }

    function deployPoolA(
        PoolA.Parameters calldata parameters_
    ) external returns (address) {
        address poolRegistry_ = poolRegistry;
        string memory poolAIdentifier_ = PoolRegistry(poolRegistry_).POOL_A();

        address poolABeaconProxy_ = _deploy(poolRegistry_, poolAIdentifier_);

        PoolA(poolABeaconProxy_).__PoolA_init(parameters_);

        _injectDependencies(poolRegistry_, poolABeaconProxy_);
        _register(poolRegistry_, poolAIdentifier_, poolABeaconProxy_);

        return poolABeaconProxy_;
    }
}

The final step is to add the PoolRegistry and PoolFactory contracts to the ContractsRegistry. If the ContractsRegistry was created under a proxy, this can be done as an upgrade.

contract ContractsRegistry is OwnableContractsRegistry {
    string public constant SYSTEM_CONTRACT_1 = "SYSTEM_CONTRACT_1";
    string public constant SYSTEM_CONTRACT_2 = "SYSTEM_CONTRACT_2";

    string public constant POOL_REGISTRY = "POOL_REGISTRY";
    string public constant POOL_FACTORY = "POOL_FACTORY";

    function getSystemContract1() external view returns (address) {
        return getContract(SYSTEM_CONTRACT_1);
    }

    function getSystemContract2() external view returns (address) {
        return getContract(SYSTEM_CONTRACT_2);
    }

    function getPoolRegistry() external view returns (address) {
        return getContract(POOL_REGISTRY);
    }

    function getPoolFactory() external view returns (address) {
        return getContract(POOL_FACTORY);
    }
}

Then the migration function can be extended with the deployment of the PoolRegistry and PoolFactory . Additionally, this extension involves deploying the PoolA implementation contract. Once deployed, the PoolA is added to the PoolRegistry via the setNewImplementations function.

import "@solarity/solidity-lib/libs/utils/TypeCaster.sol";

using TypeCaster for string;

function migration() external {
    ContractsRegistry contractsRegistry_ = new ContractsRegistry();

    contractsRegistry_.__OwnableContractsRegistry_init();

    contractsRegistry_.addProxyContract(
        contractsRegistry_.SYSTEM_CONTRACT_1(),
        address(new SystemContract1())
    );
    contractsRegistry_.addContract(
        contractsRegistry_.SYSTEM_CONTRACT_2(),
        address(new SystemContract2())
    );
    contractsRegistry_.addProxyContract(
        contractsRegistry_.POOL_FACTORY(),
        address(new PoolFactory())
    );
    contractsRegistry_.addProxyContractAndCall(
        contractsRegistry_.POOL_REGISTRY(),
        address(new PoolFactory()),
        abi.encodeWithSelector(PoolRegistry.__PoolRegistry_init.selector)
    );

    contractsRegistry_.injectDependencies(contractsRegistry_.SYSTEM_CONTRACT_1());
    contractsRegistry_.injectDependencies(contractsRegistry_.POOL_FACTORY());
    contractsRegistry_.injectDependencies(contractsRegistry_.POOL_REGISTRY());

    PoolFactory poolFactory_ = PoolFactory(contractsRegistry_.getPoolFactory());
    PoolRegistry poolRegistry_ = PoolRegistry(contractsRegistry_.getPoolRegistry());

    string[] memory poolNames_ = poolRegistry_.POOL_A().asSingletonArray();
    address[] memory poolImplementations_ = address(new PoolA()).asSingletonArray();

    poolRegistry_.setNewImplementations(poolNames_, poolImplementations_);
    poolFactory_.deployPoolA(
        PoolA.Parameters({token1: address(1), token2: address(2)})
    );

    contractsRegistry_.transferOwnership(msg.sender);
}

After executing the migration function, all you need to access the addresses of both standalone and pool contracts is a ContractsRegistry instance.

function accessContracts(ContractsRegistry contractsRegistry_) external {
    address systemContract1_ = contractsRegistry_.getSystemContract1();
    address poolRegistry_ = contractsRegistry_.getPoolRegistry();

    /// offset_ = 0, limit_ = 1
    address firstPoolA_ = PoolRegistry(poolRegistry_).listPools(
        PoolRegistry(poolRegistry_).POOL_A(),
        0,
        1
    )[0];

    SystemContract1(systemContract1_).systemContract1Method();
    PoolA(firstPoolA_).poolAMethod();
}

Production References

• dexe-network/DeXe-Protocol is entirely based on the Contracts Registry module.
